VNM x Cube Controls Direct Drives

VNM x Cube Controls Direct Drives - immagine 2

We’ve refined our bases to elevate your racing experience. Featuring a new base side hub that’s 60% lighter than the standard version, and ready-made profiles developed with esports drivers, you’ll enjoy greater immersion and performance, right out of the box

852,00 €

VNM Base

Colore

Viola
Nero
Rosso
Blu

Spedizione

Spedizione veloce con il nostro corriere partner

pagamenti

Pagamenti sicuri al 100%.

Vista 3d

In collaboration with VNM, we bring you the ultimate in direct drive technology. With telemetry-based force feedback, these wheel bases offer unmatched precision, responsiveness, and realism. Engineered for serious sim racers, they deliver pure, unfiltered performance, setting a new standard in control, immersion, and competitive racing experience.

Specs

Elite VNM Direct Drive

Servo	Customized smooth industrial servo with M8 x4 mounting holes 5 polepairs Maximum torque 18Nm Dimension: 130x130x231mm
Encoder	Absolute encoder 23b (8,388,608 CPR)
Controller	Integrated controller with single core 480Mhz MCU
Customized FFB	Can adjust strength for 11 game effects and 4 user effects Adjust smoothness for overall, damper, inertia, friction force.
Experimental Feature	Crash effect reduction Telemetry FFB for AC/ACC, iRacing, rFactor2, Le Mans Ultimate
Upgrade option	Industrial grade slipring for steering wheel (supports other brands)
Packing Box	Dimension: 50x36x25 cm Weight: 13kg
Box includes	VNM Direct Drive Xtreme USB A to B cable for wheelbase USB A to C for steering wheel EMC Stop Button for DD Quick Release Base-side only Power Adapter.

Xtreme VNM Direct Drive

Servo	Customized smooth industrial servo with M8 x4 mounting holes 5 polepairs Maximum torque 32Nm Dimension: 130x130x247 mm
Encoder	Absolute encoder 23b (8,388,608 CPR)
Controller	Integrated controller with single core 480Mhz MCU
Customized FFB	Can adjust strength for 11 game effects and 4 user effects Adjust smoothness for overall, damper, inertia, friction force.
Experimental Feature	Crash effect reduction Telemetry FFB for AC/ACC, iRacing, rFactor2, Le Mans Ultimate
Upgrade option	Industrial grade slipring for steering wheel (supports other brands)
Packing Box	Dimension: 50x36x25 cm Weight: 16kg
Box includes	VNM Direct Drive Xtreme USB A to B cable for wheelbase USB A to C for steering wheel EMC Stop Button for DD Quick Release Base-side only Power Adapter.

FAQ

Download

For software and instruction manuals

VNM Direct Drive Elite

VNM Direct Drive Xtreme

Profiles

32Nm Profile
18Nm Profile

Recensioni

Descrizione

In collaboration with VNM, we bring you the ultimate in direct drive technology. With telemetry-based force feedback, these wheel bases offer unmatched precision, responsiveness, and realism. Engineered for serious sim racers, they deliver pure, unfiltered performance, setting a new standard in control, immersion, and competitive racing experience.

Informazioni aggiuntive

Peso	16 kg
Dimensioni	50 × 36 × 25 cm
VNM Base	Elite, Extreme
Colore	Viola, Nero, Rosso, Blu
